功能特點 FUNCTIONAL
|
美國標準五舌鎖體 American standard lock core. |
|
純不銹鋼材質鎖板及把手，堅固耐用 Stainless Steel panels and handles , sturdy and durable. |
|
感應卡開啟 RF Card |
|
備用機械鎖芯采用超B級電腦鎖芯 Spare mechanical key with ultra B lockcore |
|
多級管理 Multi-management |
|
低電壓報警功能 Low voltage alarm function |
|
未上好鎖報警 Lock Failure Alarm |
技術參數 TECHNOLOGY
|
感應卡片技術 Card technology |
EM卡/ T5557卡/ Mifare1卡. EM card/ T5557 card / Mifare1 card. |
|
工作電壓 Working voltage |
DC6V直流電池 DC6V,DC battery. |
|
工作溫度 Working temperature |
- 30 ~ +60℃ |
|
工作濕度 Working humidity |
10%~85% RH |
|
功耗 Power Consumption |
靜態功耗≤20微安。動態功耗≤200毫安。 Static current:≤20 uA,Dynamic current :≤200 mA |
|
鎖板材質 Lomk shell |
不銹鋼SUS304 SUS304 stainless steel |
|
把手材質 Handle |
不銹鋼SUS304 SUS304 stainless steel |
|
適用門類型及厚度 Door Thickness |
適用于門厚度35mm以上 Door thickmess for 35mm Above |
|
面板尺寸 Panel size |
長:286.5 寬:77.2 厚:18 Length:286.5 Width:77.2 Thickness:18 |
