功能特點 FUNCTIONAL
|   | 純不銹鋼防盜門天地桿鎖體,國標通用尺寸 Stainless stell mortise,National standard dimension. |
|   | 純不銹鋼材質鎖板及把手,堅固耐用 Stainless Steel panels and handles, staudy and durable. |
|   | 一卡通Mifarel感應芯片 Mifare 1 RF card. |
|   | 高強度觸摸密碼屏,防盜窺視密碼輸入功能 High frequency password screen,with anti-peeking password inputting function. |
|   | 備用機械鎖芯采用超C級葉片鎖芯 Spare mechanical key with ultra clockcore. |
|   | 上提打反鎖功能 Handle Lifed locking |
|   | 多用戶管理 Multi-management |
|   | 低電壓報警功能 Low voltage alarm funtion |
|   | 可選配遙控器開啟 Remote control is useful. |
技術參數 TECHNOLOGY
| 感應卡片技術 Card technology | 一卡通Mifarel感應芯片 Mifare 1 RF card |
| 用戶容量 User capacity | 密碼用戶數量100組,卡用戶數量800組 100 passwords, 800 cards. |
| 工作電壓 Working voltage | DC6V直流電池 DC6V ,DC battery. |
| 工作溫度 Working temperature | -30~ +60°C |
| 工作濕度 Working humidity | 40%~85% RH (無凝霜) |
| 感應卡工作頻率 Frequency | 13.56MHz |
| 感應卡類型 Card Model | 可選擇: 標準卡片式、扣鈕式、貼膜式。 Standard formula, Buttoning style, Thin Film style. |
| 功耗 Power Consumption | 靜態功耗≤20微安。動態功耗≤200毫安。 Static current:≤20 uA,Dynamic current :≤200 mA |
| 密碼長度 Password length | 6-10位 6-10 digits |
| 適用門類型及厚度 Door Thickness | 適用于國標帶天地桿防盜門,厚度40-120mm Door thickness for 40- 120mm |
| 面板尺寸 Panel size | 長:315 寬:74 厚:26 Length:315 Width:74 Thickness:26 |
